Calibration columns are installed on the suction line of the pump with the top of the column vented back to the supply tank or drain. Using isolation valves, the column is filled with process fluid from the supply tank and drawn down in a timed, one minute test. The fluid remaining in the column at the end of the test is measured on the column’s graduated scale in both milliliters/minutes (mL/min) and US gallons/hour (US GPH).
- Two column materials and a wide range of sizes to suit every application.
- Laminated dual scale in mL/min and US GPH for simple and accurate measurements.
- Proudly made in the USA.
PVC COLUMNS
| Size |
Height |
Diameter |
Connection |
Capacity |
| 100 mL |
13.5" |
1.8" |
0.5" |
1.5 gal |
| 250 mL |
17" |
2.1" |
0.5" |
4 gal |
| 500 mL |
16.3" |
2.8" |
0.75" |
8 gal |
| 1000 mL |
25.5" |
2.8" |
0.75" |
16 gal |
| 2000 mL |
24.3" |
4" |
1" |
32 gal |
| 4000 mL |
27.5" |
5" |
1" |
64 gal |
| 10000 mL |
28.5" |
7.1" |
2" |
160 gal |
| 20000 mL |
47.3" |
7.1" |
2" |
315 gal |
End cap options:
SEALED
Glued to the cylinder for permanent vent connection. Used in applications with positive suction head.
REMOVABLE
Cap sealed with a O-ring for easy removal for cleaning. Used in applications with positive suction head.
LOOSE
Cap acts as dust cover in applications with no positive suction head. Cylinder is filled from the top.
GLASS COLUMNS
| Size |
Height |
Diameter |
Connection |
Capacity |
| 100 mL |
15.3" |
2.3" |
0.5" |
1.5 gal |
| 250 mL |
19.4" |
2.4" |
0.5" |
4 gal |
| 500 mL |
18.3" |
3.3" |
0.75" |
8 gal |
| 1000 mL |
28.1" |
3.3" |
0.75" |
16 gal |
End cap options:
Threaded end caps offered in variety of materials, two sealing O-rings, and a shield to protect the inner glass tube and calibration scale label.
