Wastewater Transfer Pulsation

Wastewater Transfer Pulsation

Problem: Vishay Measurements Group uses a Wilden 1" Air Operated Double Diaphragm pump to pull the plants processed waste water out of a pit and pump it over to the waste water plant to be processed. The reciprocating action of the pump caused pulsation in the PVC discharge pipe which caused the system to vibrate. The continuous shaking of the PVC pipe caused joints to break apart and stress caused cracking in the discharge pipe.

Spill Prevention in Contact Lens Factory

Spill Prevention in Contact Lens Factory

Problem: A highly sterile production facility manufacturing liquid materials for contact lens production experienced a critical failure of an air operated diaphragm pump. The pump’s diaphragm ruptured, causing the expensive chemical product to spill across the floor. Beyond the immediate material loss, the incident created contamination risks in a controlled cleanroom environment and exposed the process to costly downtime.

Hazardous Waste AODD Containment Failure

Hazardous Waste AODD Containment Failure

Problem: A major chemical company in Michigan uses air operated double diaphragm (AODD) pumps for unloading hazardous waste, including many different chemicals and products (e.g., acids, solvents, methyl chlorides, etc.). Each of the AODD pumps are 2 inch stainless steel; with PTFE internals, and are pumping at a flow rate of 80 to 100 gpm at 30 psi discharge pressure. The company has experienced pump diaphragm failure due to the elastomer material wearing out or damage from metal particles. When a diaphragm fails, the product goes into the air system and then out through the pump’s air exhaust. Because the product is hazardous, there is zero tolerance for spills. If a spill occurs, HAZMAT is called and the cost of cleanup can range from $20,000 to $100,000 depending on severity.

Paint Manufacturing Abrasive Slurry Diaphragm Failure

Paint Manufacturing Abrasive Slurry Diaphragm Failure

Problem: A major U.S. paint manufacturer uses 3” air operated double diaphragm pumps (AODD) in their tank farm to transfer ingredients to their paint blending process area. One of the main ingredients is titanium dioxide (TiO2) which is both high in specific gravity and very abrasive. The 3” AODD pumps sit at the bottom of holding tanks that are 25 feet tall. Pump inlet pressure is high and this combined with the characteristics of the TiO2 acts to shorten normal pump diaphragm life. When an unexpected diaphragm failure occurs, several thousand gallons of TiO2 can be lost because when a pump diaphragm fails, the TiO2 is pulled through the diaphragm on the pump’s suction stroke and then expelled out the air exhaust.

Achieving Even Application of Screen Coating

Achieving Even Application of Screen Coating

Problem: A manufacturer producing coated screens for residential and industrial windows relied on air operated double diaphragm (AODD) pumps to deliver coating material to their screen coating machines. However, pulsations generated by the pumps caused the spray nozzles to apply an uneven coating across the screens.

This inconsistency led to quality issues and required re coating, increasing both material waste and production time. Compounding the challenge, the existing equipment layout provided no vertical installation space for a traditional pulsation dampener.

Decontamination Facility Spray Pulsation

Decontamination Facility Spray Pulsation

Problem: A decontamination facility pumped acids and water through a series of 15" spray nozzles to rinse radiation from contaminated metals. However, the pulsating action of their reciprocating pumps caused uneven spray into the rinse tanks, and the metals were not rinsed completely.
